PAC Racing 1200 Series Ovate Wire Beehive Valve Spring
Your Price: $14.83
SKU: PAC-1220
In Stock
–
Top 0.650 in. / Bottom 1.000 in. ID – Top 1.095 in. / Bottom 1.445 in. OD – 1.880 in. installed Height – 0.600 in. Max Valve Lift
GTIN: 00193564529879
/home/1097991.cloudwaysapps.com/htnwxfyvzc/public_html/wp-content/themes/kadence/woocommerce/single-product/product-attributes.php:33:string 'here' (length=4)
/home/1097991.cloudwaysapps.com/htnwxfyvzc/public_html/wp-content/themes/kadence/woocommerce/single-product/product-attributes.php:37:string 'here' (length=4)
| Outer Diameter – Outer Valve Spring | Top 1.095 IN / Bottom 1.445 IN |
|---|---|
| Inner Diameter – Outer Valve Spring | Top 0.650 IN / Bottom 1.000 IN |
| Installed Height | 1.880 IN |
| Installed Load | 155 PS |
| Open Height | 1.280 IN |
| Open Load | 377 PS |
| Open Load / Height (Valve Open) | 377 LB @ 1.280 IN |
| Valve Spring Rate | 370 PS |
| Max Coil Bind | 1.210 IN |
| Max Valve Lift | 0.600 IN |
| Recommended Valve Spring Retainer – 300 Series | R310, R311, R363 |
| Recommended Valve Spring Retainer – 500 Series | R510, R511 |
| Recommended Valve Spring Seat | S112, S113 |
| Recommended Valve Spring Cup | C201 |
| Valve Spring Series | 1200 Series |
| Valve Spring Type | Ovate Wire Beehive |
| Primary Market | Circle Track|Street Performance |
